Engine type

liquid-cooled, 4-stroke, DOHC, forward-inclined parallel 4-cylinder, 4-valves

Displacement

599cc

Bore x stroke

67.0 mm x 42.5 mm

Compression ratio

13.1 : 1

Maximum power

91.0 kW (123.7PS) @ 14,500 rpm

Maximum Torque

65.7 Nm (6.7 kg-m) @ 10,500 rpm

Lubrication system

Wet sump

Clutch Type

Wet, multiple-disc coil spring

Carburettor

Electronic Fuel Injection

Ignition system

TCI (digital)

Starter system

Electric

Transmission system

Constant Mesh, 6-speed

Final transmission

Chain

Frame

Aluminium Deltabox

Front suspension system

Upside-down telescopic fork, Ø 41 mm

Front travel

115 mm

Caster Angle

24º

Trail

97 mm

Rear suspension system

Swingarm, (link suspension), Monoshock

Rear Travel

120 mm

Front brake

Hydraulic dual disc, Ø 310 mm

Rear brake

Hydraulic single disc, Ø 220 mm

Front tyre

120/70 ZR17M/C (58W)

Rear tyre

180/55 ZR17M/C (73W)

Overall length

2,040 mm

Overall width

705 mm

Overall height

1,095 mm

Seat height

850 mm

Wheel base

1,375 mm

Minimum ground clearance

130 mm

Wet weight (including full oil and fuel tank)

189 kg

Fuel tank capacity

17 litres

Oil tank capacity

3.4 litres
